Vsi Sand Making Machine

Minimum Order Quantity: Negotiate Price Negotiate
Packaging Details Standard container, spare parts will be packed in wooden cases Delivery Time 2 months
Payment Terms: T/T, L/C Supply Ability 50 sets per Month
Place of Origin: Shanghai, China Brand Name: SANME
Certification: ISO&CE Model Number: VC726, VC730, VC733, VC743, VC766, VC788, VC799

Detail Information

Capacity(t/h): 60-1804 Power: 110-2*630KW
Max Feedding Size: 100mm Warranty: One Year
Application: Mining, Sand Making, Quarry, Stone Crushing Marketing Type: Ordinary Product

Product Description

Vsi Sand Making Machine

Vertical shaft impact crusher is also named Sand making machine which features is a unique combination of rotor design, wear material and crushing equipment design. This combination has proved revolutionary in improving capacity, gaining superior product shape quality and in reducing operating and wear costs. Impact crusher is a high-efficient rock crushing equipment with home and international leading level. It is widely used for crushing of hard and crispy materials, such as rocks, grinding materials, refractory materials, cement clinkers, quartzite, iron ores and concrete aggregates. It is especially suitable for the sand and sandstone making for construction and road paving. It is more suitable for crushing mid-hardness materials and high-hardness materials. Its product is cubic, and the density of piling up is high and the iron pollution is low. It can protect our environment better with the working noise less than 75 decibels and little dust pollution.

Technical Data of VSI Series Vertical Shaft Impact Crusher:

Model Max Feed Size (mm) Rotor Speed (r/min) Throughput (t/h) Motor Power (kw) Overall Dimensions (L×W×H) (mm) Weight (kg)
VSI3000 45(70) 1700-2000 30-60 75-90 3080×1757×2126 ≤5555
VSI4000 55(70) 1400-1620 50-90 110-150 4100×1930×2166 ≤7020
VSI5000 65(80) 1330-1530 80-150 180-264 4300×2215×2427 ≤11650
VSI6000 70(80) 1200-1400 120-250 264-320 5300×2728×2773 ≤15100
VSI7000 70(80) 1000-1200 180-350 320-400 5300×2728×2863 ≤17090
VSI8000 80(150) 1000-1100 250-380 400-440 6000×3000×3420 ≤23450
VSI9000 80(150) 1000-1100 380-600 440-630 6000×3022×3425 ≤23980
Vsi Sand Making Machine 0
