400Kw Metallurgy Feeding 460mm Cone Crusher Machine
| Minimum Order Quantity: | Negotiate | Price | Negotiate |
|---|---|---|---|
| Packaging Details | Standard container, spare parts will be packed in wooden cases | Delivery Time | 2 months |
| Payment Terms: | T/T, L/C | Supply Ability | 50 sets per Month |
| Place of Origin: | Shanghai, China | Brand Name: | SANME |
|---|---|---|---|
| Certification: | ISO&CE | Model Number: | VC726,VC730,VC733,VC743,VC766,VC788,VC799 |
|
Detail Information |
|||
| Applicable Industries: | Manufacturing Plant, Construction Works , Energy & Mining | Place Of Origin: | Henan, China |
|---|---|---|---|
| Install: | Engineer Guide | After Sale Service: | Life-long Service |
| After Warranty Service: | Video Technical Support, Online Support | Warranty: | 1 Year |
| High Light: |
600t/H Mining Crushing Machine,50mm Feeding Mining Crushing Machine,Dolomite Bluestone Mining Crushing Machine |
||
Product Description
Feeding Size: 5-50mm
Processing Capacity: 20-600t/h
Range of application: Building aggregate, road fabric, cushion material, asphalt concrete and cement,etc
Applied Material: Pebble, calcite, granite, quartz, concrete, dolomite, bluestone, iron ore, limestone,etc.
| Model | Rotation Speed of Impeller (r/min) | Max Feed Size (mm) | Throughput (t/h) (Full feeding center / center plus waterfall feeding) | Motor Power (kw) | Overall Dimensions (mm) | Weight(motor not included) (kg) | |
| VC726L | 1881-2499 | 35 | 60-102 | 90-176 | 110 | 3600*1969*2200 | ≤7055 |
| VC726M | 70-126 | 108-211 | 132 | ||||
| VC726H | 96-150 | 124-255 | 160 | ||||
| VC730L | 1630-2166 | 40 | 109-153 | 145-260 | 180 | 4600*2150*2480 | ≤10000 |
| VC730M | 135-200 | 175-340 | 220 | ||||
| VC730H | 160-243 | 211-410 | 264 | ||||
| VC733L | 1455-1934 | 55 | 165-248 | 215-415 | 264 | 5500*2563*3178 | ≤14020 |
| VC733M | 192-286 | 285-532 | 320 | ||||
| VC733H | 238-350 | 325-585 | 400 | ||||
| VC743L | 1132-1504 | 60 | 230-346 | 309-577 | 400 | 5850*2740*3031 | ≤21040 |
| VC743M | 246-373 | 335-630 | 440 | ||||
| VC743H | 281-405 | 366-683 | 500 | ||||
| VC766L | 1132-1504 | 60 | 362-545 | 486-909 | 2*315 | 5850*2740*3050 | ≤21840 |
| VC766M | 397-602 | 540-1016 | 2*355 | ||||
| VC788L | 517-597 | 65 | 460-692 | 618-1154 | 2*400 | 6000*3040*3456 | ≤23220 |
| VC788M | 560-848 | 761-1432 | 2*500 | ||||
| VC799L | 517-597 | 65 | 644-967 | 865-1615 | 2*560 | 6000*3122*3625 | ≤24980 |
| VC799M | 704-1068 | 960-1804 | 2*630 | ||||
| Model | Rotation Speed of Impeller (r/min) | Max Feed Size (mm) | Throughput (t/h) (Full feeding center / center plus waterfall feeding) | Motor Power (kw) | Overall Dimensions (mm) | Weight(motor not included) (kg) | |
| VCU726L | 1881-2499 | 55 | 86-143 | 108-211 | 110 | 3600*1969*2200 | ≤6950 |
| VCU726M | 98-176 | 124-253 | 132 | ||||
| VCU726H | 132-210 | 143-300 | 160 | ||||
| VCU730L | 1630-2166 | 65 | 150-212 | 162-310 | 180 | 4600*2150*2482 | ≤9910 |
| VCU730M | 186-280 | 203-408 | 220 | ||||
| VCU730H | 220-340 | 245-480 | 264 | ||||
| VCU733L | 1455-1934 | 80 | 230-338 | 255-497 | 264 | 5500*2563*3178 | ≤13820 |
| VCU733M | 268-398 | 296-562 | 320 | ||||
| VCU733H | 327-485 | 373-696 | 400 | ||||
| VCU743L | 1132-1504 | 100 | 305-467 | 362-678 | 400 | 5850*2740*3031 | ≤21240 |
| VCU743M | 335-506 | 379-746 | 440 | ||||
| VCU743H | 375-540 | 439-800 | 500 | ||||
