Mining Metallurgy 2100t/H Coal Jaw Crusher 350mm Discharge

Minimum Order Quantity:	Negotiate	Price	Negotiate
Packaging Details	Standard container, spare parts will be packed in wooden cases	Delivery Time	2 months
Payment Terms:	T/T, L/C	Supply Ability	50 sets per Month

Place of Origin:	Shanghai, China	Brand Name:	SANME
Certification:	ISO&CE	Model Number:	JC231, JC340, JC440, JC443, JC549, JC555, JC663, JC771, JC983

Detail Information
Name:	Jaw Crusher	Capacity:	50-2100t/h
Max Feeding Size:	510mm-2100mm	Application:	Mining, Metallurgy, Construction, Highway, Railroad, And Water Conservancy, Etc.
Motor Type:	AC Motor	After-sales Service Provided::	Video Technical Support, Free Spare Parts, Online Support
Warranty Of Core Components:	2 Years	Installation:	Under Technical Guidance
High Light:	2100t/H Coal Jaw Crusher,Metallurgy Coal Jaw Crusher,350mm Discharge Coal Jaw Crusher

Product Description

Railroad 450kw 700t/H Feeding 2100mm Jaw Rock Crusher

Main Features of Jaw Crusher:

1. Model for the latest products, a wide range of applications, with a compact structure, long service life, and high work efficiency.
2. Adjustable for easy wear parts, Easy replacement of wear and spare parts.
3. High capacity, less costly and Easy to install.
4. The machine has a large crushing ratio, uniform product size, simple structure, convenient maintenance, can crush the compressive strength of a variety of materials is not more than 320 MPa, is the first choice for primary crushing equipment.
5. First-class technology, reliable pre-sale customer service quality. The products meet European CE certification standards.

WORKING PRINCIPLE OF JC SERIES JAW CRUSHER

The motor drives belt and pulley. The movable jaw swings up and down before and after through the eccentric shaft. When the movable pushes the movable jaw plate to the fixed jaw plate, the material is crushed or split into pieces. When the movable jaw and movable jaw plate springs back in the effect of eccentric shaft, the material previously have been crushed discharges from the discharge opening of the lower part. With the motor continuously rotating, the movable jaw breaks and discharges material periodically to achieve mass production.

Technical Data of JC Series Jaw Crusher:

Model	Size of Feed Opening(mm)	Discharge Range(mm)	Capacity(t/h)	Motor Power(kw)	Weight (Excluding Motor)(kg)
JC231	510×800	40-150	50-250	55-75	9052
JC340	600×1020	60-175	85-300	75-90	16460
JC3540	650×1060	110-225	120-400	75-90	16872
JC440	760×1020	70-200	120-520	90-110	27810
JC443	850×1100	80-215	170-625	110-160	34722
JC549	950×1250	110-250	260-810	132-160	50308
JC5149	1100×1250	160-300	350-900	132-160	50550
JC555	1070×1400	125-250	360-920	160-200	58907
JC5155	1170×1400	225-350	600-1100	160-200	60162
JC649	1100×1250	125-280	385-920	160-200	55954
JC659	1200×1500	150-350	400-1200	200-250	90089
JC663	1200×1600	150-350	500-1450	220-250	90789
JC771	1500×1800	150-350	600-1800	315-400	124413
JC983	1800×2100	175-350	700-2100	355-450	180000
