400Kw Metallurgy Feeding 460mm Cone Crusher Machine
| Minimum Order Quantity: | Negotiate | Price | Negotiate |
|---|---|---|---|
| Packaging Details | Standard container, spare parts will be packed in wooden cases | Delivery Time | 2 months |
| Payment Terms: | T/T, L/C | Supply Ability | 50 sets per Month |
| Place of Origin: | Shanghai, China | Brand Name: | SANME |
|---|---|---|---|
| Certification: | ISO&CE | Model Number: | Mobile Crusher |
|
Detail Information |
|||
| Raw Materials: | Granite, Limestone, Concrete, Lime, Plaster, Slaked Lime, Etc. | Capacity: | 250-480t/h |
|---|---|---|---|
| Application: | Manufacturing Plant, Construction Works , Energy & Mining | Motor Type: | AC Motor |
| Color: | Clients’ Request | After-sales Service Provided: | Rovided: Video Technical Support, Online Support, Field Installation |
| High Light: |
250t/H Mobile Impact Crusher,Plaster Aggregate Mobile Impact Crusher,Mobile Impact Crusher 242KW |
||
Product Description
mobile impact crushing station host adopts heavy super rotor, large capacity crushing chamber, heavy impact plate, alloy high wear-resistant plate hammer, hydraulic opening device and other unique design, to ensure that it has super crushing capacity and crushing effect, large feed particle size, smaller and finer discharge particle size, large crushing ratio and good product grain shape, which is widely used in low corrosive rock in gravel aggregate industry The operation of medium and fine stone crushing. It can crush low hardness ore, rock and construction waste. The broken product is cubic, with low content of needle and flake, and almost no internal crack.
1. Primary crushing, intermediate crushing and fine crushing in various medium hardness crushing processes;
2. Rock fragmentation in various mines;
3. Utilization of solid waste resources, such as house demolition, crushing of road concrete recycling;
4. Aggregate crushing in asphalt and concrete mixing station;
5. Material crushing in other industries.
| Model | MP-PH 10 | MP-PH 14 |
| Impact crusher | AP-PH-A 1010 | AP-PH-A 1414 |
| Feed opening size(mm×mm) | 810×1030 | 1025×1360 |
| Max feed size(m3) | 0.3 | 0.5 |
| Max edge length in one direction(mm) | 800 | 1000 |
| Crushing capacity(t/h) | up to 250 | up to 480 |
| Drive | diesel-direct | diesel-direct |
| Driving Unit | ||
| Engine | CAT C9 | CAT C18 |
| Performance (kw) | 242 | 470 |
| Feed hopper | ||
| Hopper volume(m3) | 4.8 | 8.5 |
| Grizzly feeder with pre-screening(two-deck) | ||
| Drive | hydraulic | hydraulic |
| Main conveyor belt | ||
| Discharge height(mm) | 3100 | 3500 |
| Drive | hydraulic | hydraulic |
| Side conveyor belt (option) | ||
| Discharge Height(mm) | 1900 | 3500 |
| Drive | hydraulic | hydraulic |
| For transportation the head-piece can be folded | ||
| Crawler unit | ||
| Drive | hydraulic | hydraulic |
| Permanent magnetic separator | ||
| Magnetic separator | option | option |
| Dimensions and weight | ||
| Working dimensions | ||
| -length (mm) | 14600 | 18000 |
| -width (mm) | 4500 | 6000 |
| -height (mm) | 4200 | 4800 |
| Transport dimensions | ||
| – length (mm) | 13300 | 17000 |
| – width (mm) | 3350 | 3730 |
| – height (mm) | 3776 | 4000 |
| Approx weight (t) | 43 | 70 |
Note: Capacity is total tons per hour passing through crusher at open circuit when bulk density of feeding is 1.6t/m³. Capacities are relative to physics character and type of feeding, feeding size and composition.
