Product Description
SMH series hydraulic cone crusher is widely used in metallurgy, Mining, cement, chemical and other industrial sectors, as well as the highway construction, water conservancy projects, construction debris, sand making, etc, The cone crusher , suitable for crushing hard and above medium hardness of all kinds of ores and rocks.
SMH series hydraulic cone crusher is a high-performance cone crusher. By optimized combination of the rotation rate, stroke and the crushing cavity, it realizes the laminated crushing and improves the yield greatly.
CAPACITY
30-1566t/h
MAX FEEDING SIZE
35mm-450mm
RAW MATERIALS
Basalt, pebbles, granite, andesite, diabase, serpentinite, quartz, iron ore, copper ore, slag, etc.
APPLICATION
Mining, metallurgy, construction, highway, railroad, and water conservancy, etc.
FEATURES OF SMH SERIES CONE CRUSHER
Strong crushing ability, high efficiency productivity, high capacity.
Hydraulic system is reliable, provide safe and effective overload protection.
Types of crushing cavity are for wide range of product size requirement.
Reasonable structure, advanced crushing principle and technical data, reliable work and low cost.
Use hydraulic adjustment and hydraulic clean cavity setting, greatly increase automation.
ADVANTAGE OF SMH SERIES CONE CRUSHER
Optimized cavity, higher capacity
The mantle of the same diameter, the crushing stroke longer, larger crushing ratio, high output, low energy consumption;The effect of laminated crushing under full load makes particle-size distribution more steady, shape of product (cubic) more excellent.
Minimize the amount of downtime
SMH Series Cone Crushers adopt hydraulic locking and overload protection. When something which cannot be broken enters into the crushing chamber, hydraulic system will release the impact force smoothly to protect the crusher, and it can get back to the former discharging setting after the foreign material getting through, which can prevent block of the crusher.
PRODUCT DATA
Technical Data of SMH Series Standard Head Hydraulic Cone Crusher:
| Model |
Max Feeding Size(mm) |
Discharge Range(mm) |
Moter Power(kw) |
Capacity(t/h) — open circuit,closed discharge(mm) |
| 9 |
13 |
16 |
19 |
22 |
26 |
32 |
38 |
51 |
63 |
76 |
89 |
| SMH120C |
160 |
22~32 |
75-90 |
|
|
|
|
120 |
130 |
150 |
|
|
|
|
|
| SMH120M |
130 |
13~26 |
75-90 |
|
70 |
85 |
100 |
120 |
130 |
|
|
|
|
|
|
| SMH120F |
102 |
9~22 |
75-90 |
58 |
70 |
85 |
90 |
110 |
|
|
|
|
|
|
|
| SMH180C |
180 |
22~32 |
132-160 |
|
|
|
|
185 |
195 |
215 |
|
|
|
|
|
| SMH180M |
140 |
13~32 |
132-160 |
|
90 |
115 |
135 |
160 |
180 |
200 |
|
|
|
|
|
| SMH180F |
60 |
9~22 |
132-160 |
60 |
80 |
100 |
120 |
140 |
|
|
|
|
|
|
|
| SMH250EC |
260 |
26~51 |
160-200 |
|
|
|
|
|
250 |
290 |
340 |
395 |
|
|
|
| SMH250C |
220 |
19~51 |
160-200 |
|
|
|
182 |
209 |
236 |
279 |
334 |
365 |
|
|
|
| SMH250M |
150 |
16~38 |
160-200 |
|
|
140 |
165 |
185 |
220 |
275 |
330 |
|
|
|
|
| SMH250F |
115 |
13~31 |
160-200 |
|
115 |
133 |
156 |
176 |
192 |
226 |
|
|
|
|
|
| SMH350EC |
315 |
38~63 |
250-280 |
|
|
|
|
|
|
|
555 |
649 |
766 |
|
|
| SMH350C |
230 |
26~63 |
250-280 |
|
|
|
|
|
366 |
430 |
468 |
629 |
657 |
|
|
| SMH350M |
205 |
22~52 |
250-280 |
|
|
|
|
296 |
343 |
387 |
427 |
479 |
|
|
|
| SMH350F |
180 |
16~38 |
250-280 |
|
|
212 |
239 |
270 |
320 |
355 |
374 |
|
|
|
|
| SMH550EC |
450 |
38~89 |
355-400 |
|
|
|
|
|
|
|
920 |
1179 |
1380 |
1475 |
1566 |
| SMH550C |
350 |
31~76 |
355-400 |
|
|
|
|
|
|
800 |
850 |
1100 |
1288 |
1398 |
|
| SMH550M |
320 |
25~63 |
355-400 |
|
|
|
|
|
612 |
735 |
815 |
980 |
1137 |
|
|
| SMH550F |
268 |
19~52 |
355-400 |
|
|
|
392 |
453 |
535 |
620 |
725 |
867 |
|
|
|
Technical Date of SMH Series Short Head Hydraulic Cone Crusher:
| Model |
Max Feeding Size(mm) |
Discharge Range(mm) |
Moter Power(kw) |
Capacity(t/h) — open circuit,closed discharge(mm) |
| 3 |
5 |
6 |
9 |
13 |
16 |
19 |
22 |
26 |
32 |
38 |
| SMH120DC |
70 |
6-19 |
75-90 |
|
|
62 |
82 |
102 |
123 |
138 |
|
|
|
|
| SMH120DM |
51 |
5-16 |
75-90 |
|
45 |
58 |
78 |
99 |
116 |
|
|
|
|
|
| SMH120DF |
35 |
3-13 |
75-90 |
30 |
45 |
58 |
78 |
95 |
|
|
|
|
|
|
| SMH180DC |
70 |
6-9 |
75-90 |
|
|
72 |
90 |
108 |
131 |
158 |
|
|
|
|
| SMH180DM |
51 |
5-16 |
75-90 |
|
68 |
76 |
95 |
118 |
145 |
|
|
|
|
|
| SMH180DF |
35 |
3-13 |
75-90 |
|
70 |
82 |
95 |
120 |
|
|
|
|
|
|
| SMH250DC |
89 |
9-22 |
160-220 |
|
|
|
126 |
168 |
196 |
215 |
252 |
|
|
|
| SMH250DM |
70 |
6-16 |
160-220 |
|
|
88 |
117 |
156 |
172 |
|
|
|
|
|
| SMH250DF |
54 |
5-16 |
160-220 |
|
63 |
86 |
115 |
143 |
169 |
|
|
|
|
|
| SMH350DEC |
133 |
13-25 |
250-280 |
|
|
|
|
262 |
308 |
322 |
358 |
385 |
|
|
| SMH350DC |
133 |
10-25 |
250-280 |
|
|
|
208 |
262 |
308 |
322 |
358 |
385 |
|
|
| SMH350DM |
89 |
6-19 |
250-280 |
|
|
136 |
186 |
233 |
260 |
293 |
|
|
|
|
| SMH350DF |
70 |
6-13 |
250-280 |
|
|
136 |
186 |
233 |
|
|
|
|
|
|
| SMH550DEC |
203 |
16-25 |
400 |
|
|
|
|
|
516 |
593 |
656 |
696 |
|
|
| SMH550DC |
178 |
13-25 |
400 |
|
|
|
|
455 |
498 |
552 |
600 |
643 |
|
|
| SMH550DM |
133 |
10-19 |
400 |
|
|
|
355 |
416 |
472 |
530 |
|
|
|
|
| SMH550DF |
105 |
6-16 |
400 |
|
|
276 |
355 |
385 |
448 |
|
|
|
|
|
