JC 340 Mining Jaw Crusher Machine High Flexibility Low Energy Consumption

Product Description

JC 340 Mining Jaw Crusher Machine High Flexibility Low Energy Consumption

Jaw Crusher JC 340 High Quality Stone Crusher Machine Price

Features:

1. Robust structure
There are two types of machine frame: welded model and assembled model. The former is for small and middle size, and the latter is for big size.
The welded type adopts large arc fillet and low stress welding method, greatly reduces the concentration stress which ensures rack equal strength in all directions, high impact resistance, even force, low failure rate.
Assembled uses advanced modularization and non-welded frame structure design of high fatigue strength and high reliability. Meanwhile machine assembly design makes transportation, and installation more convenient, especially suitable for installation in narrow and small places like undermine and high altitude mining.

2. Optimized cavity structure
Symmetrical V formed design, toggle of large obliquity, long stroke, reasonable rotor speed, allow larger materiel block in feeding, higher productivity, homogeneous output granule, less attrition for jaw plate.

3. The whole set of heavy movable jaw plate is durable.
The whole set of heavy movable jaw plate integrates forged heavy eccentric shaft, high quality bearing of heavy loading, the design of movable jaw plate optimized by finite element analysis. These features assure the stroke resistance and stability. Labyrinth seal and centralized lubricating system prevent the greese of bearing not to be contaminated, and assure the easy lubrication which results in longer function and more stability.

4. Protective planch of movable jaw plate
Heavy protective planch installed above the movable jaw plate protects internal bearing from damage caused by material falling down in feeding moment.

5. One piece cast of bearing seat
One piece cast of bearing seat assures good match with frame, and avoids unnecessary radio direction pression for bearing in fastening process which occurs usually to composed bearing seat. Therefore, bearing can function more stably.

6. Fast and easy adjustment of output granularity
JC jaw crusher adopt mechanic or hydraulic device to adjust discharge opening. Compared with shim, adjustment by double block is simpler, saver, faster, and reduces downtime.

7. Installation integrating motor & crusher
Integrative installation of motor chassis and crusher frame not only saves installation space of jaw crusher but also reduces the length of Vee belt. Thanks to synchronous movement of crusher frame, motor chassis and motor. Adjustable motor chassis can realize the adjustment of Vee-belt’s tensile force to make the Vee-belt more durable.

8. Shock absorber installation
The crusher is fixed by the device of special rubber shock absorber, which absorbs effectively the its vibration at the peak point and meanwhile, allows crusher to displace in vertical and horizontal direction. In this way, the shock to foundation would be reduced.
